PME Tuning is happy to announce our VAG MG1 Torque Patch! Newer VAG cars transmissions have locked TCUs that are not flashable, why is that a problem? It's a problem because there are torque limits in the TCU that prevent the ECU from making maximum power. This patch replaces the need to flash the TCU and achieves the same goal without requiring torque limits to be changed within the TCU, allowing the ECU to make full power while making it possible to report up to 1000nm of torque to the transmission. This torque patch can be used on cars in which the TCU is not locked as well if a full TCU tune is not desired. The torque patch has been tested on stage 3 vehicles with the ZF8 Automatic Transmission and is only recommended for up to stage 2 vehicles with the ZF 8 Speed Dual Clutch Transmission. For cars with the ZF8 Automatic Transmission, you can load the torque converter up to its mechanical limit for Launch control.
Supported and tested ECUs:
- MG1CS002 IFX TC298
- MG1CS008 IFX TC298
- MG1CP007 TC298
Possible ECUs that can be supported with your help by testing with Vehical's logging patch (Half price offered to those willing to test):
- MG1CS163 TC298 (8Y RS3 Included)
- MG1CS047 TC298
- MG1CS011 IFX TC298
- MD1CP014 TC298
- MD1CP004 IFX TC298
- MD1CP004 TC298
- MG1CS014 TC299
For any other VAG MG1 ECUs not mentioned above using tricore processors please email us at Support@pmetuning.com to check if it can be supported.
These ECUs can be found in:
- Audi
- Bentley
- Cupra
- Lamborghini
- Porsche
- Seat
- Skoda
- Volkswagen
Instructions:
1) Attach the file to the file uploader.
2) Fill out the vehicle's VIN Number.
3) Add to cart and check out.
4) Wait up to 24 hours for the Patched file to be emailed to you.
This patch requires a flash tool that can do full flashes, not calibration only flashes.
Current Tested Flash tool:
- Blfash
- Dead Beef Flash
*NOT SUPPORTED WITH MAGIC MOTORSPORTS IXI OR AUTOTUNER ONE*
Please email us if you are planning on using a different flash tool than listed above.
Contact us for bulk discounts.
IMPORTANT:
*Please allow up to 24 hours for the patch to be added to your file and emailed back to you*
*If an Incorrect VIN is supplied or you try and flash a different car other than the one you provided the VIN for, YOUR ECU WILL BRICK*
*We are not responsible for any damage that may occur to your ECU or Vehicle with the use of our patch under any circumstances*
*There are NO REFUNDS for tested ECUs while full refunds are offered for customers testing possible supported ECUs*
*If you are trying to use other custom code with the use of our patch please email use the Stock file + Modified file so we can confirm no conflicts are present*
*Don't use this patch if you are not confident in your tuning abilities*
*There's a 20MB or 20,000KB file upload limit*
Contact us with any questions you have before using our patch.
Legend
ECU - Engine Control Unit
TCU - Transmission Control Unit
VAG - Volkswagon Audi Group
